Installation
A
NOTICE! Damage hazard
• The connection to the vehicle's electrical system should be protected by a
25 A fuse for the power supply.
• The battery must be capable of supplying the required current and voltage
(chapter "Technical data" on page 15).
• Route the power supply lead stressless and secure it with cable binders in
appropriate intervals.
Route the power supply lead as illustrated (fig. a).
When doing so, you should also follow the vehicle manufacturer's guidelines.
➤ Run the wiring loom to the main power distribution box along a route where
it is protected.
➤ Connect the negative lead (black) for the power supply.
➤ Connect the positive lead (red) for the power supply via a 25 A fuse.
➤ Connect the wiring loom to the unit and fix with a cable tie in a suitable posi-
tion.
I
NOTE
Place the fuse holder no more than 0.3 m from the positive terminal of the bat-
tery.
6.8

Fixing the cover frame

A
NOTICE! Damage hazard
Tighten the screws carefully in order not to damage the cover frame.
➤ Fix the cover frame in place as illustrated (fig. b).
10
RT780
EN
