Scope of delivery

The manufacturer accepts no liability for any injury or damage to the product
resulting from:
• Incorrect assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts
provided by the manufacturer
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Dometic reserves the right to change product appearance and product
specifications.
The installation kit enables the installation of a CoolAir RT780 parking cooler in a
roof ventilation opening (hatch) provided at the plant in a Ford F-MAX driver cab.
I
NOTE
As the parking cooler uses R134a as refrigerant with a GWP > 150, there may
be national restrictions for installation the parking cooler on certain vehicles
(i.e. the EU MAC directive 2006/40/EC). Check upfront the national require-
ments or contact your Dometic representative, if it is allowed to install the park-
ing cooler on your vehicle.
5 Scope of delivery
CoolAir RT780 installation kit for Ford F-MAX
Item in
fig. 1














6
Part designation
Thread insert with flange M8
Spacer sleeve L = 18 mm, ∅ 14 mm
Thread insert with flange M6
Washer 8.5 x 20
Spring washer M8
Hex screw M8 x 40
Spacer sleeve L = 40 mm, ∅ 10 mm
Spacer sleeve L = 48 mm, ∅ 10 mm
Cover frame
Washer M6
Allen screw with cylindrical head M6 x 100
2.5 m insulating tape 10 x 20 mm
Connection cable 4 m
Cable binder
RT780
Quantity
8
8
4
8
8
8
4
4
1
4
4
1
1
2
