10 TROUBLESHOOTING

Fault
The luminaire does not
come on
The luminaire does not
come on
The luminaire does not
come on

11 TECHNICAL DATA

Electrical data:
Rated input voltage
Frequency range
Power consumption (20-3)
Input current (20-3) / (20-1)
Photometric values:
Central illuminance Ec at 0.5m (1.64 feet) distance
Light field diameter d10 at 0.5m (1.64 feet) distance
Light field diameter d50 at 0.5m (1.64 feet) distance
Color temperature
Color rendering index Ra
Color rendering index R9
Total irradiance Ee at maximum intensity
Ambient conditions for transport, storage and operation:
Ambient temperature (storage and transport)
Ambient temperature (operation)
Relative humidity (non-condensing) (storage and transport)
Relative humidity (non-condensing) (operation)
Weight:
halux LED 20-3/-1 P FX
halux LED 20-3/-1 P SX
Operating mode:
Operating mode
Classification:
halux LED 20-1 P FX / SX
Degree of protection as per IEC 60529
Classification according to Directive 93/42/EEC - Annex IX (medical device
classes)
Electrical safety test and EMC according to:
GMDN Code
Service life of light source:
LED life cycle
14
Possible cause
Contact problem
No mains voltage
LED module defective
(20-1)
(20-3)
(20-1)
Troubleshooting
Switch on again
Check mains voltage,
check all connections
Contact manufacturer
support
100-240V or 120V or 220-240V
see luminaire type plate
50/60Hz
15-22VA (12-18W)
9VA / 15VA (8.5W / 9.5W)
0.09A-0.15A / 0.07A
40'000 lx *
Ø = 18 cm (7.1") *
Ø = 9 cm (3.54") *
4400K / 3800K / 3300K *
4400K *
>93
>90
<180 W/m
* -10% / +20% tolerance
-20°C to +70°C (-4°F to +158°F)
+10°C to +35°C (+50°F to +95°F)
max. 90%
max. 75%
1.4kg (3.09 lb)
1.4kg (3.09 lb)
Continuous operation
Protection class II
IP 20
Class I
EN/IEC 60601-1
EN/IEC 60601-2-41
EN/IEC 60601-1-2
12276
30'000h (L70/B50)
User profiles
All
Electrician
By manufacturer service
only
