Maintenance of Cutting Tables

Maintenance of Cut-off Wheels

Storing of Bakelite Bonded Al

and SiC Cut-off Wheels
Maintenance of Diamond and
CBN Cut-off Wheels
Maintenance of
Clamping Devices
22
Unitom-2
Instruction Manual
The stainless steel rails (available as spare parts) should be
replaced in case they have become worn or damaged.
These cut-off wheels are sensitive to humidity. Therefore, do not mix
O
2 3
new, dry cut-off wheels with used humid ones. Store the cut-off
wheels in a dry place, horizontally on a plane support.
The precision of diamond and CBN cut-off wheels (and thus the cut)
depends on how carefully the following instructions are observed:
 Never expose the cut-off wheel to overload, such as heavy
mechanical load, or heat.
 Store the cut-off wheel in a dry place, horizontally on a plane
support, preferably under light pressure.
 A clean and dry cut-off wheel does not corrode. Therefore, clean
and dry the cut-off wheel before storing. If possible, use ordinary
detergents for the cleaning.
 Regular dressing of the Diamond and CBN cut-off wheel is also
part of the general maintenance.
It is recommended to thoroughly clean and lubricate the
Quick Clamping Device and Vertical Clamping Device at regular intervals.
Important
