Noise Level

Supplying Power

Direction of the Cut-off Wheel

4
Unitom-2
Instruction Manual
Approx. 76 dB (A) measured at idle running, at a distance of
1.0 m/39.4" from the machine.
Check that the mains voltage corresponds to the voltage
stated on the type plate on the side of the machine.
Unitom-2 is factory mounted with an electric cable. Mount a plug

on the cable according to the following:
50 hz
Phase Black and brown
Earth Yellow/green
Check that the cut-off wheel rotates in the direction indicated on the
label attached to the guard of Unitom-2. If the direction of rotation is
incorrect:
50 hz
Switch two of the phases
IMPORTANT
60 hz
L Black
1
L Red
2
L Orange
3
Earth Green
60 hz
Switch phases L and L
1 2
