Maintenance and repair
9. Calculate the distance between the stator and the armature plate as follows:
– Distance = rotor thickness + s
(For values ​ ​ o f s
10. Unscrew the sleeve bolts evenly until the calculated distance between the stator and armature plate is
reached.
11. You can now install and adjust the new rotor and the complete stator. (Refer to Mounting the
brake, Page 38.)
12. Re-connect the connection cables.
13. If necessary, deactivate mechanical shutdown of the system.
INTORQ | BA 14.0168 | 08/2019
- head height
LN
, refer to the table Rated data for air gap specifications, Page 23.)
LN
