BRAKE LINES

The brake lines connect to the trailing edge via a series of subsidiary lines.
Because of their positions they are more easily scuffed than other lines on your
glider, so they should be checked extra frequently.
The main brake lines run through pulleys connected to the rear risers. The brake
handles are tied to the main lines and conveniently positioned press-studs attach
them to the risers when not in use. This should prevent them twisting and tangling.
Adjusting brake lines
Important: the lengths of the brake lines will have been set carefully during test-
ing and manufacture. At OZONE we feel it is better to have slightly long brake
lines and to fly with a wrap (one turn of line around the hand). However, we know
that some pilots prefer the lines slightly shorter and may wish to adjust them.
Whatever you choose, make the following checks:
· Ensure both main brake lines are of equal length.
· If a brake handle has been removed for any reason, check that its line is still
routed through the pulley when it is replaced.
· When the brake handles are released in flight the brake lines should be slack.
There should be a substantial "bow" in them and absolutely no deformation of the
trailing edge.
We recommend a minimum of 10cm of free play between the brake release posi-
tion and the start of deformation on the glider. This will prevent the trailing edge
from being deformed when using the speed system.
In the unlikely event of a brake line snapping in flight, or a handle becoming
detached, the glider can be flown by gently pulling the rear risers (D-risers) for
directional control.
