Sortimo ProPartition Montageanleitung Seite 41

Installation material
Illustration Quantity
4
2
2
2
2
2
2
6
4
2
© Sortimo International GmbH | de-en-fr | ProPartition | MA-00054 | 2017-12-06 | Rev. 2.0
Reference number
MT100176
71003970
MT100170
MT100172
MT100175
71004524
71003833
6000010780
6000000628
6000010140
Designation
Washer 5.3 galvanised (5.3x10x1)
Washer 6.4 galvanised (6.4x12x1.6)
Washer 6.4 galvanised (6.4x18x1.6)
Washer 8.4 galvanised (8.4x16x1.6)
Washer 8.4 galvanised (8.4x24x2)
Washer 10.5 galvanised (10.5x20x2)
Washer 10.5 galvanised (10.5x30x2.5)
Countersunk screw M6x16 galvanised
Hexagonal screw M10x120 galvanised
Floor retainer clips pack of 2
(included with floor)
Plain bearing
