Sortimo ProPartition Montageanleitung Seite 39

Installation material
Illustration Quantity
1
2
2
4
7
7
2
4
4
4
3
© Sortimo International GmbH | de-en-fr | ProPartition | MA-00054 | 2017-12-06 | Rev. 2.0
Reference number
2000010973
2000010147
2000003268
6000010143
71003916
71004896
71010067
6000002481
MT100379
6000010691
71003833
Designation
Centre piece CRTE TW
Aluminium stop bar
596x33*10
Bracket 1-20-S
Raised flange head screw M5x45
Raised flange head screw M6x12
galvanised
Raised flange head screw M6x16
galvanised
Raised flange head screw M6x20
galvanised
Raised flange head screw M6x25
galvanised
Raised flange head screw M6x30
galvanised
Raised flange head screw M6x35
galvanised
Self-tapping screw M4.2X13 galvanised
FXR
39
