Application of the document
Representation conventions
This section includes detailed information about the symbols and highlighted text used
in this document.
Warning notices
Warning notices draw your attention to safety awareness and explain safety measures.
These are structured as follows:
Type and source of the danger
Consequences and explanation of
the dangers
 Measures for averting the danger.
DANGER
Signal words indicate dangerous situations. The meanings of the signal words are
specified below.
If the danger is not avoided, it will result in severe personal injury or loss
DANGER
of life.
WARNING
If the danger is not avoided, it can result in severe personal injury or
loss of life.
ATTENTION
If the danger is not avoided, it can result in minor or moderate injury.
ATTENTION
If the danger is not avoided, it can result in damage to property.
Operation instructions
 This symbol indicates actions that need to be carried out.
This symbol is to indicate that the screw fastening is to be tightened
to a suitable torque.
Torque values for screw fastening / tolerance for all torque values +/- 15%
M4 to 2 Nm
M5 to 4 Nm
M6 to 7.5 Nm
M8 to 20 Nm
© Sortimo International GmbH | de-en-fr | ProPartition | MA-00054 | 2017-12-06 | Rev. 2.0
This symbol is to indicate that the screw fastening is not to be
tightened. (just hand-tight)
