Storage

8.3.3

Replacing the saw chain and guide rail

Replacing the saw chain and guide rail
The saw chain and guide rail are exposed to sig-
nificant wear. Change the saw chain and guide
rail immediately if correct function is not assured.
Note: The replacement chain for the pole-mount-
ed pruner (Art. No.: 112972) can be purchased
separately.
8.3.4

Turning the guide rail

In order to avoid one-sided wear on the guide
rail, turn it every time the chain is changed.
8.3.5

Sharpening the saw chain

CAUTION! Risk of injury due to kickback.
Damaged or incorrectly sharpened saw chains in-
crease the danger of kickback! This can result in
injuries.
■
Clean the saw chain regularly.
■
Check the saw chain regularly for damage
and replace if necessary.
■
If you are not familiar with sharpening the
chain: Contact our relevant customer service.
The saw chain must be sharpened in the follow-
ing cases:
■
Only sawdust is thrown out, rather than wood
chips.
■
The pole-mounted pruner must be forced
through the wood during pruning.
For the inexperienced user: Have the saw chain
sharpened by a specialist/customer service. If
you are sharpening the saw chain yourself, heed
the following values. Accessories can be ob-
tained from specialist retailers.
Saw chain type
Round file
Depth limiter distance
T
Sharpening angle
Side plate angle
Chain tooth length a
NOTE Only remove a little material when
sharpening! We recommend using a chain sharp-
ening tool for sharpening your saw chain.
442961_a
Oregon 91 P0
Ø 5.5 mm (7/32")
0.64 mm (.025")
25°
60°
min. 3 mm
8.3.6

Cleaning the guide rail

1. Clean the guide rail, the groove of the guide
rail and the oil outlet openings regularly.
2. Use a flat file to remove the burrs that have
built up on the guide rail due to the saw
chain.
3. Turn the guide rail after each chain change/
chain sharpening in order to avoid one-sided
wear.
8.3.7 Checking and cleaning the drive
sprocket
The load on the drive sprocket (19/2) is particu-
larly intense. Therefore, perform the following
tasks:
1. Check the teeth of the drive sprocket regular-
ly for wear or damage.
2. Clean the drive sprocket and guide rail at-
tachment with a brush.
NOTE A worn or damaged drive sprocket
reduces the service life of the saw chain, and so
the drive sprocket should be renewed without de-
lay by the customer service.
8.4

Hedge trimmer attachment

8.4.1

Lubricating the pivot head (21)

The pivot head must be lubricated every 20 oper-
ating hours at the three grease nipples using en-
vironmentally friendly grease.
9 STORAGE
WARNING! Danger of explosion and fire.
Petrol and oil are highly flammable. Fire can lead
to serious injuries.
■
Do not store the appliance close to naked
flames or sources of heat.
■
Do not store the appliance in a room in which
electric tools are operated.
Thoroughly clean the appliance after each use
and – if present – attach all covers. Store the ap-
pliance in a dry, lockable place out of the reach of
children.
If the appliance is not going to be used for more
than 2 – 3 months, the following work is neces-
sary to avoid any damage:
1. Drain the fuel tank.
2. Start the engine and let it run at idling speed
until it stops.
3. Allow the engine to cool down.
45
