1 Identification
The term "device" as used in these assembly instructions always refers to the
TES (torch exchange station). The device is used in industry and in the trade as an automatic
torch exchange station.
The device is integrated in the welding cell and is used to minimize idle periods. These assembly
instructions solely describe the TES. The device may be operated only with original
ABICOR BINZEL spare parts.
1 Holding fork
Fig. 1
MON.0015.0 • 2020-05-19
2
1
2 Latching fork
Overview
1 Identification
3
3 Lifting unit
