Reset model: reset all the current model configu-
ration settings to their default. A confirmation is
requested.
In this example, the first modells selected and will be
reset to its default configuration after having touched
the Yes button.
RX setup
Set up the receiver. RX setup menu are like the
1
picture .
• Bind with a receiver: the transmitter enters in
bind mode. Once the receiver correctly bound,
press the back button to return to normal operation
(picture
• RX battery monitor: monitors the receiver
battery voltage (picture
• External sensor: do not monitor the receiver
power supply voltage but use an external sensor
instead. This is useful when the receiver is powered
by an ESC. Connect the external sensor directly
to the main battery.
1
Downloaded from www.Manualslib.com
3
).
2 ).
2
CARSON Reflex Wheel Ultimate Touch 500500516
manuals search engine
• Low voltage: set the minimum voltage when the
battery is almost empty (picture
• Alarm voltage: set the voltage under which an
audible alarm rings and the receiver battery icon
in the top tray blinks.
• High voltage: set the maximum voltage when
the battery is full.
3
D
4
).
4
