External View of Transmitter

GB
Trim switch TR1
Trim switch TR4
Trim switch TR5
Micro USB port
Throttle trigger
Receiver Reflex Wheel Ultimate Touch:
Slots
1. Steering servo (CH.1)
2. Throttle servo/ESC (CH.2)
3. Terminal for Channel 3 (CH.3)
4. Terminal for Channel 4 (CH.4)
64 CARSON Reflex Wheel Ultimate Touch 500500516
Downloaded from www.Manualslib.com
Stylus for
touchscreen
Switch SW1
Interchangeable
grip S/L
manuals search engine
2,4 GHz Aerial
Status LED
Trim switch TR2
Control steering
wheel
Trim switch TR3
Switch SW3
Power switch
On/Off
Switch SW2
Battery compartment
LCD colour touch
display
B/VCC: - Power supply
- Binding connector terminal
IN: Telemetry sensors terminal
OUT: No function
