Functions interface
D
All functions use a set of standard user interface
objects. The bottom tray can contain the following
buttons:
1
Yes: reset to default the
current displayed function
No: no operation
A title bar displays the name of the current function
or menu.
A white exclamation mark on the right of a title bar
indicates that contextual help is available. Touch it
and it will be displayed.
• To scroll down a help page, touch it anywhere on
its bottom part and slide it up.
• To up down a help page, touch it anywhere on its
top part and slide it down.
• To return to the calling function, touch the back
button in the bottom tray.
68 CARSON Reflex Wheel Ultimate Touch 500500516
Downloaded from www.Manualslib.com
2 3
manuals search engine
1 These 2 buttons respectively enable and disable
the current function.
2 The default button sets back the current page
parameters to their default values.
3 The back button returns to the previous screen.
