Display servos

This function displays in real time the position of
the 4 servos.
The test button let the 4 servos to move
slowly between their respective end points.
This allows to test the consistency of the mechanics
of the model.
Race timer
When the brake side operation is unnecessary with
a boat and some other vehicle, it can be disabled.
In Ihis example, the throttle trigger is at its neutral
position but since the boat mode is activated, the
throttle servo is at its low end point.
The race timer allows to measure time durations in
4 different modes. Touch the mode button to select
the race timer mode.
• Up timer: this timer starts to count up from 0.
It can be only started, stopped or reset to zero.
• Down timer: when the down timer is stopped, the
wheel sets the start time from 1 to 99 minutes.
Once started, the down timer counts down toward
zero. Once zero is reached, it counts up Iike an up
timer. Resetting a down timer sets it back to its start
time.
Downloaded from www.Manualslib.com
CARSON Reflex Wheel Ultimate Touch 500500516
manuals search engine
In this example, the
up timer is started.
In Ihis example, the down
timer is set to 5 minutes
but is still stopped.
