Throttle exponential
D
The throttle exponential is identical to the steering
exponential but applies to the channel 2.
The activation of the throttle exponential function
can be assigned to a push button.
The throttle rate can be assigned to a trim switch.
The throttle exponential can be assigned to a trim
switch.

Throttle curve

The throttle curve defines a 5 points broken-line
transfer curve between the throttle trigger and the
throttle servo.
5 buttons select one on the 5 points to adjust. Each
point can be independently adjusted from 0% (full
brake) to 100% (full throttle).
The vertical dotted Iine displays in real time the
throttle position. The horizontal dotted Iine displays
in real time the position of the throttle servo after
the throttle curve function has been applied.
74 CARSON Reflex Wheel Ultimate Touch 500500516
Downloaded from www.Manualslib.com manuals search engine
In this example, the second point is selected and
set to 15% and the curve is defined to compensate a
throttle servo that is too fast in the first middle and
slower in the second middle. Similarly, this curve
compensates a brake that isn't efficient enough
in the firsl middle and too efficient in the second
middle. The activation of the throttle curve function
can be assigned to a push button.
