Equipment For Combustion Engine; Rx Aerial - Carson Reflex Wheel Ultimate Touch Betriebsanleitung

Equipment for Combustion Engine

Receiver batteries and two servos are not included in the kit.
GB
To receiver battery
Receiver
Regard the
form of the
connector!
ATTENTION
When connecting the servo to the receiver
always regard the form of the connector! The
black wire is facing outward!

RX aerial

Advice
To obtain a better range, the RX aerial must be
installed perpendicularly, away from metallic
components.
60 CARSON Reflex Wheel Ultimate Touch 500500516
Downloaded from www.Manualslib.com
Receiver switch
manuals search engine
Servo Channel 3
(not included)
Servo Channel 3
(not included)
Throttle servo Channel 2
(not included)
Steering servo Channel 1
(not included)
Antenna cable
Receiver
