Main menu
The main menu can be accessed by touching the
settings icon at the bottom of the main screen.
The main menu is organized in horizontal pages.
Each page contains up to 12 icons representing
12 different functions.
The white balls in the bottom tray indicate which
menu page is displayed. The big white ball
represents the currently displayed page.
Top Tray
The top tray of the screen constantly displays the
main status of the whole system.
Displays the signal strength received by the
1
vehicle. The strongest signal is represented with
five bars. When the signal strength is lower or
equal to two bars, an audible alarm rings.
2
Displays the number and the name of the cur-
rently selected model.
Downloaded from www.Manualslib.com
Settings Main menu:
Page 1
CARSON Reflex Wheel Ultimate Touch 500500516
manuals search engine
Main menu:
Page 2
• To display the next page, touch the current page
anywhere on its right part and slide it to the left.
• To display the previous page, touch the current
page anywhere on its left part and slide it to the
right.
• To enter a function, simply touch its corresponding
icon.
• To return to the main screen, touch the back
button in the bottom tray.
1 1 2 2
3 Displays the status of the remote control battery.
If the voltage is too low, an audible alarm rings
and this symbol blinks.
4 Displays the status of the receiver battery. If the
voltage is too low, an audible alarm rings and
this symbol blinks. See further how to set up the
receiver battery alarm voltage.
D
Back
3 3 4 4
