Chorum 10 is equipped with an internal sequencer that can record and reproduce your
performances. The sequencer allows you to record notes played from the keyboard, any action
performed on the panel and through the expression pedal and the Sustain lever. MIDI messages
managed by the instrument received from the [MIDI IN] or [USB TO HOST] port are also
recorded (see par. 7.5).
The sequencer allows you to record and save up to 61 songs in the current memory unit, which can
then be retrieved using the keys of the keyboard.
It is possible to store and play songs both in the internal memory of the instrument and in a USB
stick inserted in connector [
[MEMORY] button as shown in step 16 of the par. 2.1.
The songs stored on the USB stick are saved as .mid files and named with a number according to
the key pressed on the keyboard at the time of storage (see par. 4.1). Therefore, for example, the
song associated with the first C is named "1.mid", the song associated with the second F is named
"18.mid", etc... The songs are stored in the "organ\songs" folder on the USB stick.

4.1 RECORDING

Follow this procedure to record your performance:
Press the[REC] button whose LED starts flashing to indicate that the sequencer is ready for
1.
recording.
2. Set the Tabs and panel controls as desired.
Press [START/STOP] or start playing to start recording: the [REC] LED is lit steady while
3.
the [START/STOP] LED starts flashing. During recording, you can change any of the panel
settings and they will be included in the recording.
Press [START/STOP] to end recording.
4.
Press [START/STOP] to listen to the recording you have just made. It is also temporarily
5.
stored until the instrument is switched off or until a new recording is made. If you want to
permanently store the recording in the current memory unit so that it can be recalled at any
time, press and hold the [REC] button and wait for it to flash twice, then press any key on
the keyboard that will be used later to select and play it back.
N.B.
Please note that during the final storage phase:
- saving in the internal memory, the recording previously assigned to the keyboard key is
irretrievably overwritten
- saving in the USB stick, if there is a file with the same number as that associated with the key
pressed for storage, this is irretrievably overwritten

4. USE OF THE SEQUENCER

] on the back panel. To select the current memory unit, use the
