When the second digit of the channel is entered, the first register from the left of the Manual
4.
I section flashes for a few seconds, confirming that the data has been entered correctly.
Press the [TRANSPOSER] button to complete and store the operation.
5.
N.B.
- The MIDI channel number can be set from 1 to 16.
-
The MIDI channel set applies both for transmission and reception.

5.3 TRANSMISSION OF PROGRAM CHANGE MESSAGES

For each of the 12 combinations it is possible to assign a Program Change number and enable the
transmission of the relative MIDI message each time the combination is recalled.
To store a Program Change to be transmitted on one or more of the MIDI channels managed by
the instrument, follow this procedure:
Press and hold the [TRANSPOSER] button until all the LEDs on the panel flash twice, with
1.
the LED on the [TRANSPOSER] button flashing continuously.
2. Press down the first register from the left (also indicated by PG screen printing) in the
Manual I section.
Select the combination in which you want to store the Program Change (No. 1 is
3.
preselected).
At each combination selection, the registers in the Manual I section indicate the Program
Change present, according to the numbers shown in serigraphy under the registers (see also
point 3 of par. 5.2).
The registers in the Bass section, on the other hand, show whether or not the program
change is enabled on the channel associated with the section shown by the screen printing
under the registers (see also par. 5.2). When the register is turned on, the Program Change is
sent on the channel of the relative section; when the register is turned off, the Program
Change is not transmitted.
Using the registers in the Manual I section with screen printed numbers, compose the
4.
number of the Program Change you want to save, keeping in mind that it must always be
composed of three digits. For example, if you want to enter the number "27", press the
registers "0","2" and "7". When the third digit is entered, the first register in the Manual I
section flashes for a few moments to confirm that it has been saved.
It is possible to insert Program Change in any of the 12 combinations, without leaving the
5.
procedure. Once the programming is complete, press [TRANSPOSER] twice to return to
normal use of the instrument.
Press the [TRANSPOSER] button to complete and store the operation.
6.
Chorum 10 Dlx – Chorum S10 – Chorum 10
EN - 14
