Local Off - Viscount Chorum 10 Dlx Bedienungshandbuch

Chorum 10 Dlx – Chorum S10 – Chorum 10
Each time you press, a new voice is selected from the list above. The voice change is
2.
confirmed by the flashing of the corresponding LED.
Release the [SET] button to complete and store the adjustment operation.
3.
N.B.
To quickly select the default voice, press and hold the appropriate ORCHESTRA button for a few
seconds. With this type of selection, however, the voice does not remain stored by switching off the
instrument.

3.7 LOCAL OFF

By activating the Local Off mode, the keyboard of the Chorum 10 no longer plays the internal
sound generator.
Chorum 10 allows you to set the Local Off for each individual section (Bass, Manual I, Manual II)
or for each individual voice.
This mode is also useful to avoid the annoying double note effect when connecting both [MIDI IN]
and [MIDI OUT] ports or the [USB TO HOST] port of the Chorum 10 to an external MIDI
device that then retransmits the data (e. g. a sequencer with the "thru" function enabled).
To set the Local Off of a full section, follow this procedure:
Press and hold the [TRANSPOSER] button until all the LEDs on the panel flash twice, with
1.
the LED on the [TRANSPOSER] button flashing continuously.
2. The [BASS] tabs indicate the section where you want to set the Local Off, as shown in
screen printing below the registers. Press and hold upward (as if to turn off the voice) the
register associated with the desired section.
The second and third register of the Manual I section indicates, as shown in screen printing
3.
under the register itself, the status of the Local Off. With the second register turned on,
corresponding to the number "0", the Local Off is disabled, while with the third register
turned on, corresponding to the number "1", the Local Off is activated. Press one of the two
registers to change the status of the Local Off, after which the first register in the Manual I
section flashes for a few moments to confirm the new configuration.
Press the [TRANSPOSER] button to complete and store the operation.
4.
To set the Local Off for each individual register, follow this procedure:
While holding down the [SET] button, press [TRANSPOSER]. All LED's of the panel flash
1.
twice, after which [TRANSPOSER] continues to blink and the registers are turned on or off
to show the Local Off status of each register according to the rule:
Register On: Local Off disabled
-
Register Off: Local Off enabled
-
Turn the registers off or on to set the Local Off as desired.
2.
Press the [TRANSPOSER] button to complete and store the operation.
3.
N.B.
When you set a section in Local Off, the respective voices continue to play with notes received
from the [MIDI IN] port.
EN - 9
User Manual
