angle, and replace the screws in the corresponding holes. For reassembly, proceed in reverse
order. Finally, retighten all screws.
The correct torque for the screw (Figure 50, marking B) is 10 Nm.
INfORMATION
6.9 Readjusting seat upholstery tension (Fig. 51, 52)
Should the seat upholstery stretch after extended use, it can be retightened. To do this, remove
the seat cushion and open the hook-and-loop strap underneath the seat upholstery on the left
side (relative to driving direction) (Figure 51, marking A). Remove the protective cap from the
profile tube (Figure 51, marking B) and pull out the upholstery bar (Figure 51, marking C). Now
remove the seat upholstery from the profile rail (Figure 52, marking A) and use the hook-and-
loop closure to tighten it, as necessary (Figure 52, marking B). Next, thread the seat upholstery
back into the profile rail and reinsert the upholstery rail and protective cap. Then replace the
seat cushion, ensuring that it is properly aligned.
A
64
A
B
50
C
B
51
A
52
B
