Biral SUB4X Montage- Und Betriebsanleitung Seite 54

Anhang / Annexe / Załącznik/ Anexă / Приложение
Serie
Szereg
Seria
Серия
SUB6N
Type
Tip/Тип
SUB6N 10-2 011
SUB6N 10-3 015
SUB6N 10-4 022
SUB6N 10-5 022
SUB6N 10-6 030
SUB6N 10-7 030
SUB6N 10-8 040
SUB6N 10-10 040
SUB6N 10-12 055
SUB6N 10-14 055
SUB6N 16-2 011
SUB6N 16-3 022
SUB6N 16-4 022
SUB6N 16-5 030
SUB6N 16-6 040
SUB6N 16-7 040
SUB6N 16-8 055
SUB6N 16-9 055
SUB6N 16-10 055
SUB6N 16-12 075
SUB6N 16-14 075
SUB6N 25-2 022
SUB6N 25-3 022
SUB6N 25-4 030
SUB6N 25-5 040
SUB6N 25-6 055
SUB6N 25-7 055
SUB6N 25-8 075
SUB6N 25-10 075
SUB6N 25-12 092
SUB6N 40-2 030
SUB6N 40-3 055
SUB6N 40-4 075
SUB6N 40-5 075
SUB6N 40-6 092
SUB6N 40-7 110
SUB6N 40-8 130
SUB6N 40-9 130
SUB6N 40-10 150
SUB6N 40-12 185
SUB6N 63-2 040
SUB6N 63-3 055
SUB6N 63-4 075
SUB6N 63-5 092
SUB6N 63-6 110
SUB6N 63-7 130
SUB6N 63-8 150
SUB6N 63-10 185
SUB6N 63-12 220
SUB6N 63-14 260
54
Abmessungen / Dimensions
Wymiary/ Dimensiuni/ Размеры
Artikel-Nr.
Article-no.
Artykuł nr
Articol nr.
∅ max.
Артикул DN
["] [mm] [mm]
05 4744.5502 3 148
05 4744.5503 3 148
05 4744.5504 3 148
05 4744.5505 3 148
05 4744.5506 3 148
05 4744.5507 3 148
05 4744.5508 3 148
05 4744.5510 3 148
05 4744.5512 3 148
05 4744.5514 3 148
05 4744.6502 3 148
05 4744.6503 3 148
05 4744.6504 3 148
05 4744.6505 3 148
05 4744.6506 3 148
05 4744.6507 3 148
05 4744.6508 3 148
05 4744.6509 3 148
05 4744.6510 3 148
05 4744.6512 3 148
05 4744.6514 3 148
05 4744.7502 3 148
05 4744.7503 3 148
05 4744.7504 3 148
05 4744.7505 3 148
05 4744.7506 3 148
05 4744.7507 3 148
05 4744.7508 3 148
05 4744.7510 3 148
05 4744.7512 3 148 1040
05 4744.8502 3 148
05 4744.8503 3 148
05 4744.8504 3 148
05 4744.8505 3 148
05 4744.8506 3 148 1074
05 4744.8507 3 148 1185
05 4744.8508 3 148 1296
05 4744.8509 3 148 1407
05 4744.8510 3 148 1518
05 4744.8512 3 148 1740
05 4744.9502 3 148
05 4744.9503 3 148
05 4744.9504 3 148
05 4744.9505 3 148
05 4744.9506 3 148 1074
05 4744.9507 3 148 1185
05 4744.9508 3 148 1296
05 4744.9510 3 148 1518
05 4744.9512 3 148 1740
05 4744.9514 3 148 1962
