2. Transport and storage

2.1 Delivery

It should be checked that the delivery corresponds
with the material listed on the advice note.
The submersible pump is supplied
on a Euro-pallet or disposable pallet
with packing designed for this purpose.
When transporting, attention must be
paid to the capacity of the hoist used
(lifting truck, crane) and the stability.
The transport dimensions and weights
are specified in the «Technical data».
The general accident prevention
regulations must be observed!
The pump must be handled with care.
Warning
It must never be subjected to excessive
bending stress while being moved.
The electrical cable must never be
used or bent to move the pump.
The free cable ends must on no account
be immersed or made wet in any way.

2.2 Storage regulations

The system must be protected against
Warning
moisture and frost.
The submersible pumps must not be
subjected to temperatures outside the
permitted range from –15 °C to +50 °C
during transport or storage.
The pump must be cleaned carefully
Warning
for safe storage following installation/
commissioning.
The hydraulic section must be dried
internally by blowing in compressed air.

2.3 Disposal of packing

For the benefit of the environment...
It will certainly be understood that
transport packing is essential.
Please help protect the environment
and dispose of the materials used
or utilize them further in accordance
with the relevant regulations.
3. Identification, purpose of use,
application limits

3.1 Type code

Type series
Diameter in inches
Version
Rated delivery in m 3 /h
Number of stages
Three-phase motor (1× 230 V)

3.2 Nameplate

3.3 Purpose of use

Submersible pumps are suitable for water with a solid
matter concentration of maximum 50 g/m
They are designed for the transport of drinking,
mineral, service and thermal water from filter wells,
shafts, tanks, lakes, dams and rivers.
Examples:
– Groundwater conservation and groundwater lowering
– Fire extinguishing and sprinkler systems
– Pressure boosting
– Irrigation, sprinkling, cooling, washing, spraying
– Water treatment, fountains, etc.
3.4 Application limits
Warning
– Maximum temperature of delivery medium: 30 °C
– Maximum proportion of solid matter: 50 g/m
– Minimum cover:
– Maximum immersion depth:
– Minimum rate of flow at motor
– Maximum number of starts (evenly distributed):
– Maximum operation against closed slide valves:
SUB 4 X 1 - 8 E
– Recommended distance to floor of well: 0,5 to 2 m
– No pump operation outside the characteristic curve
3110 Münsingen
Switzerland
Typ
No.
Pump type e.g.: SUB4X 1-8
Order no. (important for inquiries)
Operating point of system
(Approvals on request)
No flammable or explosive liquids must
be transported with submersible pumps.
The pumps must not be operated in
areas subject to explosion.
The transport of air and explosive
materials is strictly forbidden.
SUB4X = 1 m
SUB6N – SUB12X = 2 m
(from filter upper edge)
SUB4X = 150 m, SUB6N = 300 m
(otherwise fit flow casing):
– SUB4X (alternating current motor) = 0,00 m/s
– SUB4X (three-phase motor) = 0,08 m/s
– SUB6N ≤ 11 kW
= 0,1 m/s
SUB6N 13 – 15 kW = 0,2 m/s
– SUB6N ≥ 18,5 kW
= 0,5 m/s
– SUB8X – SUB12X on request / see separate sheets
– SUB4X = 20/h
– SUB6N = 20/h
– SUB8X – SUB12X on request / see separate sheets
2 minutes (danger of overheating)
➜ The pump must not be placed on the floor
(sludging/silting)
H m
Q l/s
