Brainlab Curve ceiling-mounted single display Planungshandbuch Seite 88

Maße
Verbindungsstück für manuelles Kameragelenk
36.5
25.5
2x45°
2.5
C-C
88 Technisches Planungshandbuch Aufl. 1.0 Curve
C
6
8.6
free space for limit stop
a
Curve CM Interface
Specification Drawing
Manual Joint Connector
(based on PF1014-1004 Rev. 000)
Dimensions stated in mm
™
Ceiling-Mounted Single Display Curve
56.5
C
Abbildung 52
™
Ceiling-Mounted Dual Display Version 1.0
