LSC20
Technical data
Mechanical data
Thread of screw
Electrical data
Operating voltage
Output signals
Current consumption
Output frequency
Downtime noise
Ambient condition:
Operating temperature
Storage temperature
Relative humidity
EMC
Protection category
Vibration resistance
Shock resistance
System data
Travel speed
Signal period
Resolution
System accuracy
Repeat accuary
LSC20 · Date 08.07.2014 · Art. No. 87296 · Mod. status 012/14
M3
5 V DC ±5 %
A, /A, B, /B, R, /R
Left and right limit switches
~140 mA
Max. 7.5 MHz / channel
1 increment / 1 MHz (per chan-
nel)
0 ... 70 °C
-20 ... 85 °C
10 ... 90 %, no condensation
EN 55011
EN 61000-4-2, -3, -6
EN 61000-4-4
IP54
< 30 g / 17 Hz
< 300 g / 0.5 ms
3 m/s
1.5 m/s
20 µm
0.1 µm / 0.05 µm
± 5 µm /m
±1 increment
Additional information
Additional information
According to RS422
High/Low active (program-
mable) PP 3.3 volt max.
CVTTL compatible
High > 2.4 V DC,
Low < 0.4 V DC
With terminating resistor
120 Ω
Additional information
Interference resistance /
immission
Emitted interference /
emission
EN 60529, only with mating
connector or protective cap
EN 60068-2-6 (axial,
radial)
EN 60068-2-27 (half sine)
Additional information
in resolution 0.1 µm
in resolution 0.05 µm
Bidirectional
