LSC20
46

Transport, storage, maintenance and disposal

Mechanical data
Housing
Cable length
Bending radius
Cable sheath
Connector
Weight
Weight of cable
Sensor/band reading dis-
tance
12 Transport, storage, maintenance and disposal
Transport and storage
Handle, transport and store optical sensor with care. Pay attention to the
following points:
• Transport and / or store sensors in the unopened original packaging.
• Protect the sensor from harmful physical influences including dust,
heat and humidity.
• Do not damage connections through mechanical or thermal impact.
• Prior to installation inspect the sensor for transport damages. Do not
install damaged sensor.
Maintenance
With correct installation according to chapter
requires no maintenance.
Disposal
The sensor's electronic components contain materials that are harmful for
the environment and are carriers of recyclable materials at the same time.
Therefore, the optical sensor must be recycled after it has been taken out
of operation ultimately. Observe the environment protection guidelines of
your country.

13 Technical data

Aluminium
1.0, 3.0 und 5.0 m
Double-shielded cable,
ø 3.6 mm
Bending cycles 20 x10
≥20 mm
PVC
15-pol. D-Sub
~8 g
~14 g/m
1.0 ±0.15 mm
LSC20 · Date 08.07.2014 · Art. No. 87296 · Mod. status 012/14
12
the optical sensor
Additional information
6
Static operation, dynamic
operation
Sensor
Metal housing
Sensor without cable / con-
nector
