LSC20
Installation
Note: all procedures below must be performed at ≤ 1m/s relative motion
NOTICE
between the sensor and the scale.
Correct orientation of the scale for Left/Right Limit calibration is shown
NOTICE
below. The "D" datum edge from the SIKO Interface Drawing is designated
as the "Top" of the scale. The Reference/Limit track is also the "Top" track
on a scale (tape).
1. Prior to calibrating tick off the corresponding boxes
• Calibrate GOP (option)
• Calibrate reference mark (option)
• Set left limit (option)
• Set right limit (option)
Sensor/tape calibration
2. Press the Start Cal button
3. Move the sensor back and forth in an area with no reference or end
Reference mark calibration
4. Move the sensor back and forth beyond the reference mark until the
End mark calibration
5. Move the sensor to the left end mark and press the Set button (Left
6. Move the sensor to the right end mark and press the Set button (Right
7. Calibration completed
8. The " Calibration completed" message disappears after a few seconds,
