LSC20
Installation
5. Press the Browse button to locate the LSC20.inf driver Installation
6. Verify that the correct path and filename are shown and press the Next
7. Press the Finish button.
Windows XP, Vista, 7, and 8:
1. Connect the USB cable between the host computer and the Diagnos-
2. When the electronics are on,, Windows will notify you it has found new
3. The wizard may prompt "Can Windows connect to Windows Update to
4. Select "Install from a list or specific location (Advanced)" and press
5. Select "Include this location in the search".
6. Press the Browse button to locate the SIKO_USB.inf driver installa-
7. Verify that the correct path and filename are shown and press the Next
8. Press the Finish button.

10.4 Using the Software

1. To Run Software, go to directory C:\Program Files\SIKO\Diagnostic
Run Diagnostic Tool Software
Connect the encoder to the Diagnostic Tool before connecting USB cable.
NOTICE
Connect the USB cable to the diagnostic tool.
LSC20 · Date 08.07.2014 · Art. No. 87296 · Mod. status 012/14
press the Next button.
file. It is located in the directory C:\Program Files\SIKO\Diagnostic
Tool. Once this file is selected press the OK button.
button.
tic Tool / Sensor.
hardware prompting you with a "Found New Hardware" wizard.
search for software?" Select "No, not this time" and press the Next
button.
the Next button.
tion file SIKO.inf driver. It is located in the directory C:\Program Files\
SIKO\Diagnostic Tool. Once this file is selected press the OK button.
button.
Tool. Double-click SIKO.exe.
English 41
