Hardware for the Compact ComposTumbler
Item
1a
10-32 X 3/8 Machine Screw, Slotted Truss Head, Steel, Zinc Plated
1b
10-32 Serrated Flange Locknut
3a
10-24 X 1/2 Special Phillips Truss Head Shoulder Bolt, Steel, Yellow Zinc Plated
3b
#10 SAE Flat Washer Steel, Zinc Plated
3c
10-24 Nylon Insert Lock Nut, NM, Steel, Zinc Plated
4a
1/4-20 Acorn Cap Nut High Crown (7/16X19/32), Steel, Zinc Plated
5a
1/4-20 X 3 1/4 Hex Head Cap Screw Grade 2, Steel, Zinc Plated
5b
1/4-20 Wing Nut Steel, Zinc Plated
6a
10-32 X 3/8 Machine Screw, Slotted Truss Head, Steel, Zinc Plated
6b
#10 SAE Flat Washer Steel, Zinc Plated
6c
#10 Medium Split Lock Washer, Steel, Zinc Plated
6d
10-32 Hex Nut Grade 2, Steel, Zinc Plated
6e
10-32 Serrated Flange Locknut
6f
Latch Hook, Zinc Plated
6g
Latch, Steel, Zinc Plated
7a
#6 X 5/16 Phillips Pan Head Type B Sheet Metal Screw, Steel Zinc Plated
8a
1/8 X 3/4 Cotter Pins Stl Zinc
10a
3/8 X 1 1/2 Fender Washer Steel, Grade 2, Zinc Plated
10b
3/8-16 Hex Two Way Locknut , Steel, Zinc Plated
10c
3/8-16 X 4 Hex Head Cap Screw, Grade 2, Steel, Zinc Plated
11a
1/4-20 X 3/4 Hex Head Cap Screw, Grade 2, Steel, Zinc Plated
11b
1/4-20 X 1 1/2 Hex Head Cap Screw, Grade 2, Steel, Zinc Plated
11c
1/4 Medium Split Lock Washer, Steel, Zinc Plated
11d
1/4-20 Finished Hex Nut Steel , Zinc Plated
STEP 1
1a
1b
STEP 3
3a
3b
3c
Description
Step 1
Step 3
Step 4 & 5
Step 6
Step 7 & 8
Step 10
Step 11
STEP 4 & 5
4a
5a
5b
STEP 6
6a
6b
6c
6d
6f
6g
Qty
5
5
12
12
12
6
2
2
8
4
4
4
4
2
2
1
1
2
2
2
1
All hardware can be found in the enclosed hardware
6
bags. You will see that the items needed for each
7
step have been grouped together.
7
STEP 7 & 8
7a
8a
STEP 11
11a
6e
STEP 10
10a
11b
10b
11c
11d
10c
3
