Mantis Compact ComposTumbler CT02001 Montageanleitung Seite 2

Tools You Will Need
• 3/8" wrench
• 7/16" wrench
• 9/16" wrench
• Adjustable wrench
• Plain (or needle nose) pliers
• Flat screwdriver
• Phillips screwdriver
Everything else you will need is included with your
Compact ComposTumbler.
Drum Assembly Parts
Item Part # Description
1 CT02054-00 Drum Panel A
2 CT02055-00 Drum Panel B
3 CT01839-00 Door
4 200239 Endcap
5 CT01698-00 Aerator Base
6 CT01699-00 Aerator Cap
7 CT01691-01 Tie Rod
Frame Assembly Parts
Item Part # Description
8 CT02052-00 Drive Support
9 CT01915-00 Drive Handle
10 CT02053-00 Brace
11 CT02050-00 Frame Leg
12 CT02051-00 Strut
13 200240 Drive Gear
14 CT02048-00 Grip
15 CT02049-00 Grip Cap
16 CT02047-00 Stub Axle
2
Compact ComposTumbler™
Assembly Instructions
