DRIVE GEAR AND FRAME ASSEMBLY
STEP 7 – INSTALLING THE GRIP
WHAT YOU'LL NEED
Tools: Philips screwdriver
Hardware: 7a - (1) Philips pan head sheet metal screw
Parts: Item 9 - (1) Drive handle
Item 14 - (1) Grip
Item 15 - (1) Grip cap
7.1
Slide the grip onto the end of the drive
handle.
7.2
Push the grip cap into the end of the
handle, making sure to align the holes.
Secure the grip cap with the sheet
metal screw and Philips screwdriver.
10
Grip Cap
Grip
