Mini COUNTRYMAN Betriebsanleitung Seite 375

Zambia
ZMB/ZICTA/TA/2017/6/6
ZMB/ZICTA/TA/2018/8/37
Telematics Communication
Box
Europe
European Union: Declaration of
Conformity
Hereby, Peiker acustic GmbH & Co. KG dec-
lares that the radio equipment type TPLow,
TCB-01 TCB ECE, TCB-01 TCB ECE GPS,
ATM-01 R2-ECE-3G, ATM-01 T2-ECE-3G,
ATM-01 R2-ECE-4G, ATM-01 T2-ECE-4G,
ATM-01 R2-ECE-4GW , ATM-01 T2-
ECE-4GW is in compliance with Directive
2014/53/EU. The full text of the EU declara-
tion of conformity is available at the follo-
wing internet address: http://www.valeo-
clientportal.com
License Texts and Certifications
Online Version für Sach-Nr. 01402913302 - X/19
Technical information
TPLow, Frequency Band and transmission
power:
– GSM 880-915 MHz - 33dBm
– GSM 925-960 MHz - 33dBm
– GSM 1710-1785 MHz - 30dBm
– GSM 1805-1880 MHz - 30dBm
– GNSS 1575.42 MHz
TCB-01 TCB ECE, Frequency Band and
transmission power:
– GSM 880.2-914.8 MHz - 24dBm
– GSM 925.2-959.8 MHz - 24dBm
– GSM 1710.2-1784.8 MHz - 24dBm
– GSM 1805.2-1879.8 MHz - 24dBm
– UMTS 882.4-912.6 MHz - 24dBm
– UMTS 927.4-957.6 MHz - 24dBm
– UMTS 1922.6-1977.4 MHz - 24dBm
– UMTS 2112.6-2167.5 MHz - 24dBm
TCB-01 TCB ECE GPS, Frequency Band and
transmission power:
– GSM 880.2-914.8 MHz - 24dBm
– GSM 925.2-959.8 MHz - 24dBm
– GSM 1710.2-1784.8 MHz - 24dBm
– GSM 1805.2-1879.8 MHz - 24dBm
– UMTS 882.4-912.6 MHz - 24dBm
– UMTS 927.4-957.6 MHz - 24dBm
– UMTS 1922.6-1977.4 MHz - 24dBm
– UMTS 2112.6-2167.5 MHz - 24dBm
– GNSS 1575,0 MHz GNSS 1602,0 MHz
ATM-01 R2-ECE-3G, Frequency Band and
transmission power:
– GSM 880.2-914.8 MHz - 33dBm
– GSM 1710.2-1784.8 MHz - 30dBm
– GSM 824.2-848.8 MHz - 33dBm
– GSM 1850.2-1909.8 MHz - 30dBm
– UMTS 830.0-840.0 MHz - 24dBm
– UMTS 882.4-912.6 MHz - 24dBm
