Mymodes; Switching Mymodes With The Cockpit App - Ottobock Genium 3B1-3 Gebrauchsanweisung

Adaptive swing phase control
Instantaneous adaptation to varied walking cadences and to changes of the pendular mass (e.g.
varying footgear) ensures the knee always achieves the swing flexion target angle within (+/-) one
degree. The swing phase extension and flexion resistance experienced by the user are auto-
adaptive.
The flexed and partially loaded knee will also disable the stance phase on slopes and ramps to
allow for greater knee flexion and more ground clearance in the swing phase.

9 MyModes

With the help of adjustment software, the O&P professional can activate and configure up to
5 MyModes in addition to the basic mode. These can be selected by using the Cockpit app. Only
the first 3 MyModes can be selected using movement patterns. Switching by using movement
patterns has to be activated in the adjustment software by the O&P professional.
These modes are intended for specific motion patterns or postures (e.g. inline skating...). Set­
tings can be adjusted using the Cockpit app (see Page 77).

9.1 Switching MyModes with the cockpit app

INFORMATION
Bluetooth on the prosthesis must be turned on in order to use the Cockpit app.
If Bluetooth is switched off, it can be turned on by turning the prosthesis upside-down (function
only available in basic mode) or by connecting/disconnecting the battery charger. Bluetooth is
then turned on for approx. 2 minutes. During this time, the app must be started and used to
establish a connection. If required, Bluetooth on the prosthesis can be switched on permanently
afterwards (see Page 78).
INFORMATION
If the Volume parameter is set to '0' in the Cockpit app (see Page 75) or if mute mode (silent
mode) is activated, there are no beep signals.
Once a connection to a prosthesis has been established, the cockpit app can be used to switch
between the MyModes.
81
