Flexicode

Cleaning and Maintenance

DANGER!
Risk of death by electric shock!

Before opening the housing cover, disconnect the printing system from the mains supply and wait for a moment
until the power supply unit has discharged.
NOTICE!
When cleaning the label printer, personal protective equipment such as safety goggles and gloves are recommended.
Maintenance task

General cleaning.

Clean the transfer ribbon drawing roller.
Clean the printhead.
Replace the printhead.
Adjust the angle.
NOTICE!
The handling instructions for the use of Isopropanol (IPA) must be observed. In the case of skin or eye contact,
immediately wash off the fluid thoroughly with running water. If the irritation persists, consult a doctor. Ensure good
ventilation.
General Cleaning
CAUTION!
Abrasive cleaning agents can damage the direct print module.

Do not use abrasives or solvents to clean the outer surface of the label printer.

Remove dust and paper fuzz in the printing area with a soft brush or vacuum cleaner.

Clean the outer surfaces with an all-purpose cleaner.

Clean theTransfer Ribbon Drawing Roller

A
B
130
Frequency
As necessary.
Each time the transfer ribbon is changed or
when the printout is adversely affected.
Each time the transfer ribbon is changed or
when the printout is adversely affected.
In case of errors in printout.
In case of an unequal use of the printhead.
A soiled drawing roller can lead to reduced print quality and can
affect transport of material.
•
Remove the cover.
•
Remove transfer ribbon from the direct print module.
•
Remove deposits with the roller cleaner and a soft cloth.
•
If the roller (A) appears damaged, replace it.
