Key:
Standard layout

I/O Parameters

Keys: , , ,
I/O Port 1-8 & I/O Port 9-16
(I/O Port 1-8 & I/O Port 9-16)
Key:
Debouncing
Key:
Start signal delay
Key:
Not ready: error
Key:
Save signal
Key:
I/O Profile
118
On: If a print order is started without previous definition of layout, the standard layout (device
type, firmware version, build version) is printed.
Off: If a print order is started without previous definition of layout, an error message appears in
the display.
, , ,
Definition of port functions. 2 sign show the current setting for each port.
The first sign specifies the following:
I = Port operates as Input
O = Port operates as Output
N = Port has no function (not defined)
These settings cannot be modified.
The second sign specifies the following:
+ = Active signal level is 'high' (1)
−
= Active signal level is 'low' (0)
x = Port is deactivated
& = Function is executed at each change of the signal level
s = Status can be enquired/influenced (in connection with Netstar PLUS) by
= interface. The printer-internal function is deactivated.
Indication of debounce time of the dispenser input.
Value range: 0 - 100 ms.
Intermittent mode only
Indication in time per second of the delay for the start signal.
Value range: 0.00 ... 9.99.
On: If a print order is active but the direct print module is not ready to process the order (e.g. if it
is already in 'printing' mode), then an error message appears.
Off: No error message appears.
Intermittent mode only
On: The start signal for the next label can already be released during printing the current label.
The signal is registered from the printing system. The printing system starts printing the next
label immediately after finishing the current one. Therefore time can be saved and performance
be increased.
Off: The start signal for the next label can only be released if the current label is printed to the
end and the printing system is again in 'waiting' state (output 'ready' set). If the start signal was
released already before, so this is ignored.
Selection of the existing configuration Std_Direct or StdFileSelDirect. The appropriate
assignment is indicated in the operating manual.
