Intermittent Mode
Keys: , , ,
Mode
Key:
Transfer ribbon correction
Key:
Expert parameters
Key:
Printhead down time
Printhead up time
Key:
Printhead valve reaction
time
Key:
Tension
Ribbon Mode

Device Settings

Keys: , , ,
Field handling
116
,
Selection of ribbon save mode.
Off: Ribbon save set to Off.
Standard: Maximum ribbon save performance, i.e. with this setting there is no loss of transfer
ribbon (apart from the safety distance of 1 mm, so the print fields are not printed one into the
other).
0 mm = It is always so far retreated that an optimal ribbon save is reached.
Default: 0 mm
−xx mm = The retreat can be made smaller.
+xx mm = The retreat can be made larger.
Password protected menu
Enter password, press key
indicated:
PhDownT = printhead down time in ms:
Is used from ribbon save algorithm to use for the calculation of start time of printhead downward
movement.
PHupT = printhead up time in ms:
Is used from ribbon save algorithm to calculate if a field ribbon save can be made or not.
PhVReactT = valve reaction time in ms:
The time is calculated when to start with printhead upward movement.
Indication of length that is transported forwards after measuring the transfer ribbon.
0: The transfer ribbon is retracted after each printout over the complete print length, i.e. no
ribbon save between the individual layouts.
1: The transfer ribbon is only retracted over the printed sector, i.e. the gaps between the layouts
were not optimised.
When changing the layouts, the transfer ribbon is positioned automatically
, ,
Off: The complete print memory is deleted.
Keep graphic: A graphic res. a TrueType font is transferred to the direct print module once and
stored in the direct print module internal memory. For the following print order only the modified
data is transferred to the direct print module. The advantage is the saving of transmitting time
for the graphic data.
The graphic data created by the direct print module itself (internal fonts, bar codes, ...) is
generated only if they were changed. The generating time is saved.
Delete graphic: The graphics res. TrueType fonts stored in the internal memory is deleted but
the other fields are kept.
Restore graphic: At the end of the print order the printed order can again be started at the
direct print module. All graphics and TrueType fonts are again printed.
Exception: With column printing always full columns must be printed (number of pieces always
multiple of the columns). Deleted columns are not restored.
English
to confirm the entry and the following parameters are
