No. Description
1 8 pin 12V Power Connector (ATX12V1)
2 2 x 288-pin DDR4 DIMM Slots (DDR4_D2, DDR4_C2)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_D1 DDR4_C1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
6 8 pin 12V Power Connector (ATX12V2)
7 CPU Fan Connector (CPU_FAN1)
8 Addressable LED Header (ADDR_LED1)
9 RGB LED Header (RGB_LED1)
10 ATX Power Connector (ATXPWR1)
11 Front Panel Type C USB 3.2 Gen2 Header (F_USB31_TC_1)
12 USB 3.2 Gen1 Header (USB3_7_8)
13 SATA3 Connectors (SATA3_7_8)
14 SATA3 Connectors (SATA3_5_6)
15 SATA3 Connectors (SATA3_3_4)
16 USB 3.2 Gen1 Header (USB3_5_6)
17 Clear CMOS Button (CLRCBTN1)
18 System Panel Header (PANEL1)
19 Power Button (PWRBTN1)
20 Reset Button (RSTBTN1)
21 SATA3 Connector (SATA3_2)
22 SATA3 Connector (SATA3_1)
23 USB 2.0 Header (USB_1_2)
24 Power LED and Speaker Header (SPK_PLED1)
25 Chassis / Waterpump Fan Connector (CHA_FAN1/WP)
26 Chassis / Waterpump Fan Connector (CHA_FAN2/WP)
27 Addressable LED Header (ADDR_LED2)
28 RGB LED Header (RGB_LED2)
29 Clear CMOS Jumper (CLRMOS1)
30 Front Panel Audio Header (HD_AUDIO1)
31 Chassis / Waterpump Fan Connector (CHA_FAN3/WP)
32 CPU / Waterpump Fan Connector (CPU_FAN2/WP)
