Item Qty. Part No.
Description
1
1
600267
Base
2
2
901009
Strut, Pole to Base
3
1
900953
Lift Assembly
4
1
FR908006 Top Pole Section
5
1
901453
Middle Pole Section
6
1
FR908181 Bottom Pole Section
7
2
108843
Wheel Bracket
8
2
600056
Wheel, 3.5 Inch
9
1
10884401 Rod, Axle
10
1
203099
Nut, Ny-lock, 5/16-18
11
2
203063
Nylon Insert Lock Nut, 3/8-16
12
1
202662
Bolt, Hex Head, 5/16-18 x 4-1/2 Long
13
2
600272
Screw Cap, Base Rear
14
13
203100
Hex Flange Nut 5/16-18
15
1
900998
Bracket, Pole Mount
16
2
203053
Carriage Bolt, 5/16-18 x 4 Long
17
1
20279501 Logo, NBA
18
4
203153
Bolt, Hex Head, 5/16-18 x 0.75 Long
19
1
200503
Cover, Black OR
200504
Cover, Red
20
6
206303
Washer, Flat, 1/4
21
2
201596
Screw, 1/4 x 1.25
22
1
201580
Board Pad, Center Section
23
1
20157901 Board Pad, Right Section
24
1
20157801 Board Pad, Left Section
25
1
203470
Washer, Flat, 1.5 O.D.
26
4
208891
Spacer, .38 I.D. x .67 Long
27
1
208292
Spacer, 0.344 I.D. x 1.31 Long
28
1
600270
Cover, Front
29
4
206244
Bolt, Hex Head, 1/2-13 x 8 Long
30
4
201642
Spacer, Plastic, .530 I.D. x 0.625 Long
31
5
206340
Lock Nut, Hex 1/2-13
32
2
901454
Elevator Tube, Lower - Long
33
2
204838
Spring, Counter Balance
34
1
Rim
35
2
901401
Elevator Tube, Upper - Short
PARTS LIST - See Hardware Identifier
Hardware kit is designed for more than one
style of basketball system. Not all hardware
will be used.
Item Qty. Part No.
36
2
201682
37
2
900867
38
1
600137
39
2
200520
40
1
202605
41
1
203617
42
1
206990
43
1
44
4*
208892
45
1
206089
46
1
511680
FR511680 Label, Height Adjustment and Moving,
47
6*
208505
48
2
208452
49
1
108181
50
2
203679
51
6
203218
52
1
203479
53
1
200516
54
1
900033
55
1
206048
56
1
200318
57
1
208760
58
1
203795
59
2
208890
60
4
202871
* YOU MAY HAVE EXTRA PARTS WITH THIS MODEL.
NOTE:
8
Description
Spacer, 0.530 I.D. x 1.875
Plate, Triangle, (Black)
Cap, Pole Top
Screw, #8 x 3/4 Long
Bolt, Hex, 1/2-13 x 4.25 Long
Cap, Base
Reinforcement Bracket
Net
Bolt, Hex Flange, 5/16-18 x 1.625 Long
Spacer, Plastic, 0.530 I.D. x 3.5 Long
Label, Height Adjustment and Moving
French
Carriage Bolt, 5/16-18 x 1.75 Long
Gasket, Screw Cap
Plate, Pole Mouting
Bolt, Hex Head, 3/8-16 x 2 Long
Washer, Flat, 5/16
Bolt, Hex Flange, 5/16-18 x 1.75
Cover, Bolt End, Vinyl
Bracket, Slam Jam
Bolt, Tee, 3/8-16 x 3.25" Long
Bracket, Reinforcement, Slam Jam
Spring, Rim
Nut, Special, 3/8-16
Bolt, Hex 3/8-16 x 5.625" Long
Screw, 1/4 x .75
