System Description
2.5
Glossary
SMR
Start of measuring range. Maximum overlapping between sensor and the injection needle groove.
EMR
End of measuring range. Minimum overlapping between sensor and the injection needle groove.
Injection needle
450 µm
Sensor
+5 V
(+7.5 V)
0 V
0 %
-5 V
(-7.5 V)
SMR, valve closed
Fig. 2 Output signal LS04(01)
NLS3181
200 µm
+5 V
(+7.5 V)
0 V
100 %
0 %
-5 V
(-7.5 V)
+5 V
(+7.5 V)
0 V
100 %
0 %
-5 V
(-7.5 V)
EMR, valve open
System adjustment at Micro-Epsilon in the
ideal state
50 µm
100 %
