Virtual Mode

The Virtual mode allows you to display side by side the live ultrasound
image with the 3D virtual probe representation in space.
Preparing an Interventional
Procedure in Virtual Mode
This section describes how to prepare an interventional procedure.
Defining Ultrasound Targets
The Virtual mode allows you to define up to 7 biopsy targets or Risk
Areas.
1. Click on New US Target
A virtual target is displayed on both sides.
2. Move the Trackball
3. Use the TouchRing
value is displayed in live)
4. Press Select
to validate the target.
The target appears on the list.
68 Aixplorer® Fusion/Navigation User's Guide
to position the target
PW
or knob to resize the target (the diameter
