This chapter describes how to configure the Fusion/Navigation feature.
Settings
Press the icon in the icon menu bar on the right side of the
screen to access the configuration menu.
The Settings menu is divided into 2 tabs:

• System Accuracy

• Other Settings
System Accuracy
The system accuracy tab (see picture above) allows you to configure the
sensor port assignments.
It is divided in 3 sub-tabs:
• Needle Calibration Test
• Sensor Port Assignment
• Sensor Positions
Aixplorer® Fusion/Navigation User's Guide 97
