Symbol
LOT
Batch Number
QTY
Quantity
REF
Reference
SN
Serial Number

Alarm System

The following alarms display pop-up windows:
Alarm condition
Needle calibration (VirtuTRAX)
Needle calibration failure (VirtuTRAX)
Aixplorer® Fusion/Navigation User's Guide
Meaning
Message
-Previous calibration detected
-There is a previous needle calibration
with length "xx" mm saved
-Do you want to calibrate again?
-Take the Needle and do a
pivot movement and rotation
-Keep needle tip in fixed position
-Be aware that the error of the
displayed needle position increases
proportionally to the needle length!
-Calibration failed!
Needle Tip probably changed
position during movement
Keep needle tip in fixed
position for calibration
-Calibration failed!
The needle is placed
in the wrong direction
-The needle needs to be inserted
in the direction of the arrow
15
