Supersonic AIXPLORER MultiWave Bedienungsanleitung Seite 30

LED State
FAST BLINKING
RED/ORANGE (>2Hz)
• A Transducer sensor (Model 800)
NOTE
These clips are to be used to attach the sensor cable to the transducer
cable. Twist the clip (as shown below) to firmly attach the cables.
• Mid-Range Transmitter
24 Aixplorer® Fusion/Navigation User's Guide
Description of
board status
Run-time Diagnostic Error
Possible Error
Conditions resulting
in LED state:
One of the run-time
diagnostics has failed.
Primary suspect is a
removed transmitter.
(This shows up as a
TX Temp Sense error)
Secondary suspects
might be TX Temp.
Sense or EU Temp Sense
(over-heating problem)
