Connecting to the driveBAY

The following sections explain how to connect the different devices to
the driveBAY.
How to Connect the Transmitter
to the driveBAY
1. Connect the mid-range transmitter cable to the connector marked
'Transmitter' on the front of the driveBAY
2. Align the slot on the top of the transmitter cable's plug with the
connector
3. push the plug into the connector until it clicks into place
CAUTION
The transmitter weighs 2.6kg (5.73lbs). Grasp it firmly before moving
it.
4. Set up the transmitter in a non-magnetic location (such as wood or
plastic, but never on the floor), preferably on the optional transmitter
cart
Try to keep at least a 61cm (24 inch) radius around the transmitter free
from any magnetic object or electrical wiring (which means keeping
the transmitter at least that distance away from the Aixplorer®)
WARNING
Do not use the Fusion/Navigation feature if the transmitter fell down.
Do not use the Fusion/Navigation feature if the transmitter is damaged.
Aixplorer® Fusion/Navigation User's Guide 35
