Attaching the Sensor to the
Bracket
WARNING
Ensure the device is securely attached, failure to do so could result in
inaccuracy.
WARNING
Do not use if the sensor fell down.
Attach the sensor to the bracket by putting the sensor side with the small
notch (see picture below) on the sensor mount area of the bracket.
Aixplorer® Fusion/Navigation User's Guide 45
