WORKINGMAN'S 2X10C - FRONT PANEL FEATURES
• Discrete Solid State Front End
• Balanced XLR Output
• Tuner Out Jack
• High and Low Sensitivity 1/4" Input Jacks
• Gain Control with LED peak clipping indicator
• Aural Enhancer Control
• Bass Level Control
• Lo Mid Level Control
• Mid Level Control
• Hi Mid Level Control
• Treble Level Control
• Effects Blend Control
• Variable Limiter with Pull Defeat Option
• Master Volume Control
• Speakers (both internal and extension) On/Off Switch
• Stereo Headphones Jack
• Single Open Rack Space for effects unit of your choice
WORKINGMAN'S 2X10C - REAR PANEL FEATURES (chassis and cabinet)
• Side-Chain Effects Loop (Effects Send and Effects Return 1/4" jacks)
• Extension Speaker 1/4" Output Jack
• Speaker Fuse
• Line Fuse
• AC Power Cord Receptacle
• Internal Speaker On/Off Switch
• 3-Way Tweeter Mode Selector Switch (Full Range, -6db, Off)

SPECIFICATIONS

Power Ratings (minimum)
260 Watts @ 8 ohms (internal cabinet)
400 Watts @ 4 ohms (with 8-ohm extension cabinet)
Minimum Impedance (amplifier)
4 ohms
Frequency Response (power amplifier)
-3dB @ 20 Hz and 40 kHz
Speaker Complement
(2) 10" custom designed cast-frame SWR drivers
(1) LeSon TLX-1 Piezo Tweeter
