Technical Data

Technical Data
Ambient conditions
Operation
Storage
CE mark
Type of protection of housing
Performance test
Central unit
Weight
Dimensions with cable inlet
Cable entry
Switching outlets
Power supply
Fuses
Power input
78
–20 to 40°C
10 to 90% rel. humidity
700 to 1300 hPa
0 to 30°C for transmitters and battery module
–20 to 70°C for central unit, relay and converter module
10 to 95% rel. humidity
700 to 1300 hPa
Electromagnetic compatibility
(Directive 89/336/EEC)
Low voltages
(Directive 72/23/EEC)
IP 54, EN 60 529
A VarioGard central unit, together with the CO transmitter,
successfully underwent a qualification test according to
VDI 2053, conducted by the Rhineland Technical
Inspectorate (Inspectorate job no. 432-989713) in 1999.
approx. 2.2 kg
240 mm x 200 mm x 90 mm
M20 x 1.5; 6 mm to 12 mm
M25 x 1.5; 9 mm to 16 mm for mains supply
5 relay contacts x max. 5 A / 250 V AC
max. 5 A / 30 V DC
min. 0.1 A / 10 V AC/DC
230 V AC / 110 V AC, 50/60 Hz
see information in unit
< 55 VA
