Dräger VarioGard Gebrauchsanweisung Seite 73

Remove slave from the system bus –
Display then reads:
or:
Connect new slave – Display:
Change other slaves in the same way.
The displayed number of slaves changed increases after each change –
Display e.g.:
When changing is completed:
u
Press [ ] key to quit function and display menu option again.
The following error message may appear when changing transmitter upper
parts:
Only slaves of the same type can be exchanged.
– Display if a slave is replaced by a different type (e.g. a CO transmitter by
an NH transmitter or a relay module):
3
The function cannot be executed in this case.
Menu mode
Changing transmitter upper parts
Connect slave !
0 Slaves changed !
Connect slave !
Line disconnected !
New slave detected !
1 Slaves changed !
New slave detected !
5 Slaves changed !
MENU:
CHANGE SLAVES
Slave type are diff. !
0 Slaves changed !
73
